Ultrasonic cleaning machine
Ultrasonic machine:
Dimensions: w970 x d730 x h850 mm
Cleaning bath dimensions: w700 x d500 x h400 mm
Weight: 75 kgs
Ultrasound Effect: 4200 Watt
Temperature control: 20-50°C, 2500 Watt
Timer control: 1-60 minutes
Water Connections: Filling port, drain port and overflow port
Electrical connections: 380V or 480V (US), 16A
Material: 2mm stainless steel. Insulated tank and lid
Delivered with CE conformity
Cleans an average of 6 crates/hour
Pre-soak sink table:
Dimensions: w1020 x d730 x h850 mm
Weight: 20 kgs.
Material: 2mm stainless steel
Optional added length. (+700mm)
Speeds up cleaning to 10 crates/hour
Rinsing sink table:
Dimensions: w800 x d730 x h850 mm
Rinsing sink dimensions: w700 x d500 x h400 mm.
Weight: 25 kgs.
Stainless industrial rinsing faucet
Water Connections: Faucet, drain port.
Material: 2mm stainless steel
Optional drying area to the right of sink. (+700 mm).
Sorting table:
Dimensions: w1020 x d730 x h850 mm
Weight: 15 kgs.
Material: 2mm stainless steel
Suitable for 2 crates
Optional added length for 3 crates. (+400mm)
Electrostatic dust filters
Model 1:
Fully automatic and remote controlled.
Suitable room size ~500 m3
Dimensions: L970 x H400 x W450 mm
Weight: 38 kg
Electrical connection: 220V or 110V (US)
Power consumption: 125 Watt
Noice level: 52 dBA (Quiet office)
Filters: Pre-filter, Electroststic filter (ESP), Carbon filter
CE conformity
Model 2:
Fully automatic and remote controlled.
Suitable room size ~1000 m3
Dimensions: L1495 x H400 x W450 mm
Weight: 65 kg
Electrical connection: 220V or 110V (US)
Power consumption: 190 Watt
Noice level: 54 dBA (Quiet office)
Filters: Pre-filter, Electroststic filter (ESP), Carbon filter
CE conformity
UltraGrip soap
ClimbLabs UltraGrip cleaning soap has been custom made for ultrasound cleaning climbing holds. The soap is bio degradable, harmless to handle when diluted, and can be let directly to your drain once used.
With dilution to 4% you only use 6 liters of soap each time you change the water in the ultrasonic cleaning tank.
You will be able to clean more than 40 crates with average sized holds before you need to change the water and add new soap.
The soap comes in 6 liter canisters to ensure easy and safe handling. No dosing, just empty the canister.
6 liter canister price is: 60 EUR. (focus on safety)
30 liter canister price is 250 EUR.
Plastic crates and storage
Euro plastic crates for handling and storage
Euro Crates have already been widely accepted as climbing holds storage solution. They are modular and stackable, and the sizes are suitable for comfortable lifting and handling. We have designed the ultrasonic cleaning machine for a perfect fit with Euro crates.
ClimbLab plastic crates have been carefully chosen to be compatible with the ultrasonic cleaning soap and cleaning temperatures. The hard material and the perforated design are crucial for efficient cleaning of your holds.
Our general advice is to have only one layer of holds and fit the crate height accordingly. This will protect the holds and give a better visual presentation of your holds in storage. Route setters can quickly obtain an overview of holds and pick out the ones that inspire them. Adjusting the height accordingly will result in easy handling with no more than 10-12 kg in each crate.
The system is also compatible with the US crate format 23,75" x 15,75". E.g. the open grit storage straight wall containers from Akro Mils.
Height 60 mm.
Suitable for footholds, crimps, and other smaller holds.
You can fit up to 100 small holds in this crate size.
You can fit 5 of these crates in the ultrasonic machine.
Price: 7 EUR
Height 100 mm.
Suitable for medium holds.
You can fit up to 30 medium holds in this crate size.
You can fit 3 of these crates in the ultrasonic machine.
Price: 8 EUR
Height 150 mm.
Suitable for large holds.
You can fit up to 10 large holds in this crate size.
You can fit 2 of these crates in the ultrasonic machine.
Price: 10 EUR
Height 200 mm.
Suitable for very large holds.
You can fit up to 10 very large holds in this crate size.
You can fit 1 of these crates plus a 100mm crate in the ultrasonic machine.
Price: 11,5 EUR
Height 300 mm.
Suitable for very large holds or smaller volumes.
You can fit up to 5 small fiberglass volumes in this crate size.
You can fit 1 of these crates in the ultrasonic machine.
Price: 13 EUR
Crate trolleys
Trolleys compatible with Euro crates and with large rubber wheels allows for easy and safe transport of your holds from wall - to cleaning area - to storage area - and back to the wall.
We recommend to stack no more than 1 meter in height to prevent tilting of stacked crates.
One crate trolley
This trolley fits one stack of crates.
Large rubber wheels and rugged design.
Price: 30 EUR
Two crate trolley
This trolley fits two stacks of crates.
Large rubber wheels and rugged design.
Price: 149 EUR
Crate storage shelf system
Many gyms lack space and the storage room for holds needs to be optimized. Our shelf system is compatible with the Euro crates and allow for compact storage and easy accessibility. The system is extremely robust and easy to assemble.
Give us the dimensions of your storage area and let us suggest a perfect solution that optimizes your storage capacity and workflow.
Sizes available with 4 to 8 shelfs in w1500 x d600 x h2000 mm or w2000 x d600 x h2000.
Prices from 170 EUR
